 Introduction

ETEL EA-P2M-300-4 Position Controller

Dual axis independent drive channel, single axis continuous output 7.5A current compatible with linear motor

Supports EtherCAT high-speed bus, 500 μ s real-time cycle, minimal multi axis synchronization error

Compatible with EnDat, TTL, 1Vpp multi class encoders, supporting dual encoder closed-loop feedback

Built in tooth slot force and friction compensation algorithms, smooth and vibration free motion operation

Equipped with high-speed position triggering capture function, suitable for visual synchronous positioning conditions

Equipped with dedicated ComET debugging software, parameter tuning and waveform observation operations are simple

48-340V wide DC bus voltage input, suitable for various industrial power supply units

10kHz/20kHz adjustable PWM carrier, stable and abundant low-speed torque output

Integrated STO safety cut-off circuit, rapid shutdown protection against overtravel and faults

Built in motion trajectory filtering effectively suppresses platform vibration and shortens setting time

USB debugging interface, supports firmware upgrade, quick backup and copying of program parameters

Multi channel isolated digital input/output, capable of external limit and probe sensing signals

Metal shielding integrated shell, anti electromagnetic interference compatible with dust-free precision production line

DIN rail standard installation structure, compact layout inside the electrical control cabinet, saving space

Industrial grade long-lasting components, semiconductor and optical equipment operate stably at full load for a long time

ETEL EA-P2M-300-4 position controller has high positioning accuracy and strong synchronization performance, and is a specialized servo control spare part for precision linear motion platforms

Product imag
