AMAT 0090-B828X power module

AMAT 0090-B828X power module

 Introduction

AMAT 0090-B828X power module

Specially designed to support semiconductor process equipment for application materials, compatible with cavity control unit power supply

Multi channel precision DC output with extremely low ripple, ensuring stable power supply for precision circuits in wafer equipment

Built in soft start circuit, suppresses power surge and avoids damage to internal components due to impact

Integrate four layers of safety protection including overvoltage, overcurrent, short circuit, and overheating, and immediately cut off the output in case of abnormal conditions

Metal fully shielded shell effectively isolates electromagnetic interference from RF and frequency converters

Specialized dust-proof and anti-corrosion structure for clean rooms, suitable for environments such as etching and thin film deposition in dust-free workshops

Wide range AC input, output parameters without offset under small fluctuations in grid voltage

High conversion efficiency design, low heat generation during long-term full load operation, reducing heat dissipation load

Onboard power status monitoring circuit, real-time upload voltage and current fault signals to the main control

Standardized plug-in terminal block, disassembly and maintenance without the need to modify the original circuit

Industrial wide temperature element device, capable of continuous and stable operation around high and low temperature process chambers

Compact modular body, suitable for equipment cabinets with small built-in installation space

Original factory full load aging factory inspection, AMAT equipment of the same model can be directly replaced

Seismic reinforcement internal PCB layout, equipment platform movement and vibration conditions are less prone to failure

Support remote start stop and voltage fine-tuning, compatible with automated production line linkage control logic

AMAT 0090-B828X power module provides pure power supply and comprehensive protection, and is a dedicated original power supply spare part for semiconductor wafer process equipment

Product imag
