6SL3130-6TE23-6AB0 power module

6SL3130-6TE23-6AB0 power module

 Introduction

6SL3130-6TE23-6AB0 power module

Rated 36kW power output, DC bus 600V, 60A power supply suitable for multi axis servo system

Three phase 380-480V wide AC input, compatible with industrial standard power supply grid

Built in integrated air-cooled heat dissipation structure, stable heat dissipation during long-term operation at full load

Equipped with DRIVE CLiQ communication interface, it can quickly network and communicate with S120 driver components

Book style compact cabinet size, rail installation saves internal space of the electrical control cabinet

Equipped with a pre charging circuit, the voltage level gradually increases to avoid sudden high current surges

Integrated multi-layer circuit safety protection for overvoltage, overcurrent, short circuit, and overheating

Supports a common DC bus architecture, allowing multiple motor modules to work together in parallel

Energy regeneration feedback design, motor braking electric energy is returned to the power grid to reduce energy consumption

Built in EMC filtering circuit to suppress harmonic interference and adapt to precision automation production lines

Standard control voltage adapter, no additional accessories required for wiring assembly

50/60Hz universal power frequency compatibility, compatible with both domestic and international workshop power supply

IP20 protection level, dustproof and moisture-proof, suitable for conventional indoor electrical control environment

Siemens S120 system comes with original matching, compatible with the same series of drivers for direct replacement

Industrial grade durable power devices with low failure rate during continuous operation at full load

The 6SL3130-6TE23-6AB0 power module has stable power supply and high integration, and is a dedicated rectifier power supply unit for SINAMICS S120 multi axis servo system

Product imag
