TEL E281-005021-11 Control Card

TEL E281-005021-11 Control Card

 Introduction

TEL E281-005021-11 Control Card Product Features

TEL E281-005021-11 is compatible with Tokyo Electronics etching and thin film deposition semiconductor equipment, responsible for overall signal logic control.

Multiple digital IO channels, synchronously collecting various status signals of door locks, air pressure, and limit switches

High speed output control circuit, precise driving of actuating components such as solenoid valves and relays

Built in hardware safety interlock logic, emergency stop and cabin door abnormality immediately cut off the process circuit

Optoelectronic isolation signal channel, isolated from RF and motor interference, stable signal transmission

Equipped with a dedicated FPGA computing chip, real-time processing of device flow control instructions

Compatible with the original factory exclusive communication protocol, capable of high-speed interaction of process data with the device controller

Onboard fault self-test program, automatically verifies channel and circuit status upon power on

Complete overcurrent, overvoltage, and overheating protection to prevent voltage fluctuations from damaging the board

Standard rack plug-in structure, separate disassembly and assembly without the need for machine shutdown and maintenance

Industrial grade precision PCB process, cleanroom operates continuously 24/7

Power off parameter memory function, automatically retains process control configuration after restart

Multi level signal compatibility, suitable for various industrial signals such as 24V DC and TTL

High density integrated cabling occupies a small installation space in equipment control cabinets

Real time upload of channel fault codes for easy and quick identification of line issues

The original factory has strong compatibility and can directly replace old control boards of the same specifications

TEL E281-005021-11 is the core signal control component of TEL semiconductor equipment, ensuring stable operation of wafer processes.

Product imag
