TEL CX81-050055-V3 Printed Circuit Board

Nikon S9037-0902N Image Sensor

Product Details Introduction

TEL CX81-050055-V3 Printed Circuit Board

Introduction

TEL Tokyo Electronics CX81 series original PCB, compatible with etching and thin film deposition semiconductor machines, responsible for cavity signal acquisition and logic control.

Multiple analog and digital IO channels, collecting pressure and temperature sensing signals

Onboard communication circuit, connected to the main control of the whole machine to transmit process data

Line partition isolation to resist electromagnetic interference in clean workshops

Built in overcurrent and electrostatic protection to protect onboard precision chips

LED status indicator light, quickly locate channel disconnection fault

Chemical nickel gold surface process, stable long-term plug-in contact

Multi layer high-density wiring with low signal transmission delay

Three proof coating circuit board, resistant to dust and trace process gases

Plug in card rack structure, easy to disassemble, replace and maintain

Store basic process parameters, no need to recalibrate after power failure

Equipped with heat dissipating copper foil, 24-hour continuous operation with stable temperature control

The silk screen channel identification is complete, and the maintenance wiring is clearly distinguished

Compatible with TEL's entire range of etching, CVD/PVD process equipment

Modular component layout, separate replacement for local faults

CX81 boards of the same series have universal size interfaces and interchangeable spare parts

ending

TEL CX81-050055-V3 has stable signal transmission, durability, and corrosion resistance. It is an original control PCB accessory specifically designed for semiconductor vacuum chambers.
