AMAT 0010-02977 RF Matcher

AMAT 0010-02977 RF Matcher

Product Details Introduction

AMAT 0010-02977 RF Matcher Product Features

AMAT 0010-02977 is a specialized RF matching device for semiconductor equipment, suitable for etching, deposition and other processes. It has precise impedance matching and strong stability. Its core features are as follows:

Adapt to the 13.56MHz standard RF frequency band and the mainstream frequency of semiconductor processes.

50 Ω standard impedance design, matched with RF power supply and process chamber load.

Automatic impedance matching, fast response, low reflected power, and high transmission efficiency.

High power tolerance, compatible with kilowatt level RF power supply, meeting mass production needs.

Built in precision adjustable capacitors and inductors, with a wide matching range and high accuracy.

Integrated power sensing module for real-time monitoring of forward/reflected power.

Industrial grade sealed structure, resistant to corrosive gases such as Cl ₂ and NF ∝.

Fanless design, no organic materials inside, reliable long-term operation.

The working temperature ranges from 0 ℃ to+55 ℃, suitable for harsh semiconductor operating conditions.

Gold plated connector, anti oxidation, low contact resistance, stable signal.

Support remote communication, compatible with AMAT original system, easy to integrate.

Equipped with overvoltage, overcurrent, and overheating protection, and automatic alarm for abnormalities.

Compliant with RoHS standards, environmentally friendly and lead-free, safe and compliant.

Compatible with AMAT P5000, Producer and other platforms, easy to replace.

72 hour aging test after leaving the factory, stable long-term operation, and long service life.

In summary, the AMAT 0010-02977 RF matching device meets the stringent requirements of semiconductor plasma processes with precise matching, strong corrosion resistance, and high stability, and is the core supporting component of AMAT equipment.

Product imag
