SBX92304886 controller module

SBX92304886 controller module

Product Details Introduction

SBX92304886 Controller Module (Dedicated for Sinfonia Semiconductor Equipment)

1. New Fenia original factory control board, compatible with LAM and AMAT etching machine vacuum motors and precision shaft drives

2. Built in high-speed DSP computing chip, closed-loop control DC servo, micrometer level travel positioning control

3. Compatible with multiple types of encoder signal acquisition, providing real-time feedback on shaft speed, position, and load data

4. Multiple isolated I/O terminals, connected to on-site sensing components such as vacuum pressure, limit, and gas source

5. Onboard graded fault indicator light, quick maintenance of power supply, communication overload, and abnormal drive zoning

6. Integrated protection against overcurrent, overvoltage, overheating, and static electricity to withstand instantaneous fluctuations in the workshop power grid

7. Built in EMI filtering wiring to isolate RF clutter interference and prevent servo step loss and coordinate drift

8. PCB full board three proof sealing coating, suitable for low dust and constant temperature conditions in semiconductor dust-free workshops

9. Gold plated pin interface, earthquake resistant and anti-oxidation, stable contact performance maintained during high-frequency start stop of equipment

10. On board power-off storage chip, motion parameters and point formula are saved during power-off, and debugging is not required during restart

11. Equipped with a dynamic gain adaptive program, the output torque parameters are automatically optimized for load changes

12. Standard cabinet plug-in specifications, easy disassembly and assembly, interchangeable with SBX95 series spare parts for replacement

13. Support serial bus communication, can be connected to the upper computer for program download and remote monitoring

14. Industrial wide temperature element device selection, 20~32 ℃ dust-free room continuous full load operation 24/7

15. After undergoing aging calibration at the factory and being assembled on the machine, it can be put into wafer process production

SBX92304886 is a precision servo control core module for semiconductor coating and etching equipment

Product imag
