Kawasaki 3NT520B-A037 Robot Controller

Kawasaki 3NT520B-A037 Robot Controller

Product Details Introduction

Kawasaki 3NT520B-A037 Robot Controller

1. Equipped with Kawasaki NT520 clean wafer handling robot and semiconductor cleanroom dedicated main control unit

2. Built in dedicated servo computing chip, controls 5-axis joint linkage, accurately grasps 300mm wafer

3. Equipped with original clean system firmware, suitable for high-speed cycling operation of FOUP wafer box loading and unloading

4. Multiple sets of servo bus interfaces, directly connecting the main servo motor and encoder signal circuit

5. Optoelectronic isolation I/O port, compatible with cleanroom access control, vacuum detection, and air source sensing components

6. Panel classification fault indicator light, quick troubleshooting of power, communication, and servo overload fault zones

7. Integrated multi-level voltage regulation protection, suitable for dust-free workshop voltage regulation power supply, resistant to instantaneous voltage surges

8. Onboard EMI precision filtering to isolate RF interference from cleanroom equipment and prevent coordinate shift jumps

9. Full board PCB with three anti dust sealing technology, suitable for Class 1 dust-free and low dust working environment

10. Gold plated European style plug-in terminals, earthquake resistant and oxidation resistant, not easily prone to poor contact under frequent start stop conditions

11. Industrial low-temperature selected components, constant temperature dust-free room 20-26 ℃ continuous all-weather stable operation

12. Built in power-off parameter storage chip, point and speed formula data are permanently retained after shutdown

13. Support online programming of handheld teaching devices, fine adjustment of point positions, and quick on-site modification of rhythm parameters

14. Compatible with models starting with suffix A in the same series, no need to rewrite firmware for spare parts replacement

15. Factory clean aging debugging of the whole machine, matched with 3NT520A body, can be put into operation and used on the machine

Kawasaki 3NT520B-A037 robot controller is the core control center of semiconductor wafer handling equipment

Product imag
