Product Details Introduction

V7768-330001 is an industrial single board computer with GE/Abaco 6U VME architecture, commonly used for equipment main control operations.

1. Equipped with a Core 2 dual core processor, with a maximum clock speed of 2.16GHz and abundant computing performance

2. Supports up to 2GB DDR2 memory and onboard large capacity L2 cache

3. Equipped with dual gigabit Ethernet ports as standard, supporting remote network boot via PCIe

4. Equipped with four USB 2.0, dual serial ports, and dual SATA storage interfaces

5. Reserve PCI-X PMC expansion slot, which can be equipped with daughter board to expand IO points

6. Compatible with CF card solid-state boot disk, with a maximum expansion of 8GB storage

7. Equipped with a 945GM chipset and a built-in PCI to VME bus bridge chip

8. Compliant with the VME64X bus specification, capable of running as a master or slave CPU

9. Support deployment of VxWorks, Linux, XP embedded multi class systems

10. Passive heat dissipation design, no built-in fan suitable for dust-free enclosed cabinets

11. Wide temperature hardware selection, excellent stability in high and low temperature operating conditions

12. The front panel integrates a keyboard and mouse interface, making on-site debugging and wiring convenient

13. The hardware comes with a built-in bus error self check, which quickly locates the fault location

14. Military grade circuit board coating, resistant to vibration and electromagnetic interference

15. Commonly used replacement main control spare parts for semiconductors, rail transit, and military equipment

V7768-330001 is a core control card for industrial control systems.

Product imag
