Product Details Introduction

Bobst 07470000DD, 0704170401 707-MS spool register module

1. Adapt to the Bost Registron printing and die-cutting unit, specializing in controlling the roll diameter of the material axis and storing material feeding data

2. Connect to the main control 701 motherboard bus and collect real-time pulse signals from the spool encoder

3. On board registers store parameters such as roll diameter, speed, and tension, while power-off data is retained

4. Multi channel signal input, linked tension sensing and variable frequency drive unit

5. Optoelectronic isolation circuit, isolated motor frequency conversion interference, stable data transmission

6. Partition indicator light, intuitive prompt for power, communication, and register abnormalities

7. Built in overcurrent and overvoltage protection to prevent chip damage during power grid fluctuations

8. PCB three proof coating, resistant to workshop ink dust and humid environment

9. Onboard EMI filtering circuit reduces clutter and prevents register value jumps

10. Gold plated European style pins, directly inserted into cabinet slots for quick disassembly and replacement

11. Industrial wide temperature element device, continuous and stable operation under high and low temperature production conditions

12. Independent grounding layout, releasing static electricity to prevent data confusion and parameter loss

13. Factory fixed program, compatible with 707-KL and 707 series board buses

14. Single channel independent operation, single spool failure does not affect other workstations

15. Factory aging machine calibration, no need to debug or rewrite parameters for direct installation on the machine

Bobst 07470000DD, 0704170401 707-MS spool register module is a dedicated module for data acquisition and storage of equipment feeding spools

Product imag
