Bobst 701-1106B main control circuit board

Product Details Introduction

1. Bost die-cutting/box pasting machine core control board, coordinating the overall action logic scheduling of the machine

2. Backplane bus slot installation, compatible with 703-KS electrical control box, docking with 704 and 707 series daughter boards

3. Onboard original factory curing control program, with machine parameters stored on the onboard storage chip

4. Multi channel bus communication port, linked servo, solenoid valve, various detection and sensing boards

5. Optoelectronic isolation input circuit to isolate strong electrical interference and ensure stable signal transmission

6. Partition LED status light, intuitive display of power, communication, and fault status

7. Integrated multi-level regulated power supply, 24V converted to multiple weak current sources to supply power to all components on the board

8. EMI filtering circuit to resist electromagnetic interference from workshop frequency converters and motors

9. Built in triple protection against overvoltage, short circuit, and static electricity to prevent abnormal voltage from burning the motherboard

10. PCB three proof coating, resistant to oil, toner, dust, and moisture, suitable for packaging workshop working conditions

11. Gold plated fingers and terminal blocks, resistant to oxidation and shock, and less prone to loose connections during long-term operation

12. Wide temperature industrial grade components, continuous full load operation in the range of -10 ℃~65 ℃

13. Independently grounded wiring, quickly releases static electricity, and prevents program confusion and crashes

14. Same as the 701 series multiple motherboard programs, spare parts can be directly replaced on the computer

15. Factory online aging test, complete machine debugging, no need to rewrite program during installation

The Bobst 701-1106B main control circuit board is the central motherboard of the entire 700 series control system
