BOBST 0704157601 Printed Circuit Board

BOBST 0704157601 Printed Circuit Board

Product Details Introduction

BOBST 0704157601 is the main control/driver type printed circuit board (PCB) for the Bosch 707 series control rack, used for core control and power drive of high-speed die-cutting/gluing machines such as MASTERFOLD and EXPERTCUT.

Original Factory Number: 0704157601 (Standard Material Number)

Functional positioning: Integrated control+signal processing+power drive board

Model adaptation: 707 series rack, MASTERFOLD/EXPERTCUT/NOVA equipment

Circuit level: multi-layer fiberglass board, including digital logic, analog amplification, and power conversion area

Core chip: equipped with main control MCU, motion control chip, and optoelectronic isolation module

Signal interconnection: docking with 707-MM-064, 704-1097-07 and other boards

Drive capability: Integrated low-power drive, direct drive solenoid valve, contactor

Power management: onboard DC-DC, input 24V, output ± 15V/5V

Communication interface: onboard parallel bus+external dedicated bus, high-speed data exchange

Status monitoring: power/operation/fault LED array, quickly locate problems

Protective design: Three proof coating (moisture-proof/dustproof/anti ink), suitable for harsh workshops

Golden Finger: Thickened gold plating process, shock resistant, plug and play resistant, anti-oxidation

Wide temperature operation: -10 ℃~+60 ℃, tolerant of temperature fluctuations in the workshop

Installation method: Standard 707 rack slot, plug-in type with no wiring replacement

Replacement feature: Directly replace with the same number, automatic parameter matching, no need for re debugging
