BOBST 0701244000 Interconnection Interface Board

BOBST 0701244000 Interconnection Interface Board

Product Details Introduction

The BOBST 0701244000 interconnect interface board is a Bosch old 701 rack system interconnect and signal transfer PCB, used for multi board data exchange and external port expansion in die-cutting/gluing machines.

Original factory number: 0701244000 (701 series standard spare parts)

Model adaptation: 701 rack, MASTERFOLD/EXPERTCUT old models

Functional positioning: Three in one board interconnection+external interface+signal buffering

Bus bridging: connecting 701 main control with I/O and communication board, dedicated bus relay

Interface extension: Introduce RS232/RS485, encoder, handwheel and other ports

Signal buffering: Digital/analog signal isolation, amplification, strong anti-interference

Level matching: 5V/24V interconversion, compatible with different electrical specifications of the board

Multi channel: high-density wiring terminals, coordinated multi-point signal interconnection

Status indicator: Power/communication/fault LED, quickly locate connection issues

Power Distribution: Onboard DC-DC, providing stable voltage to the main control/interface board

Industrial protection: Three proof coating, dustproof, anti ink, moisture-proof

Reinforced gold fingers: thickened gold plating, shock resistant and plug resistant, suitable for vibration working conditions

Wide temperature operation: -10 ℃~+60 ℃, suitable for workshop temperature difference

Slot installation: 701 rack direct insertion, replacement without wiring or debugging

Plug and play: directly replace the same number, automatically match parameters, and quickly put into production
