Gasonics 95-1260 C Operating Interface Panel

Gasonics 95-1260 C Operating Interface Panel

Product Details Introduction

1、 Product Overview

Gasonics 95-1260 C is an Operator Interface Panel designed specifically for Gasonics plasma processing equipment. It is used for human-machine interaction, allowing operators to control, monitor, and set parameters for the equipment's operating status. It is one of the core input/output devices of the equipment control system.

This panel typically includes a display screen (possibly LCD/LED), function buttons, status indicator lights, etc., integrated into the front console of the device.

2、 Technical parameter description (typical features, specific models subject to physical objects)

Display format: Integrated LCD or LED display screen

Key layout: combination of function keys/soft keys/navigation keys

Communication interface: Communicate with the main control PLC or embedded controller through serial or parallel interface

Installation method: panel installation, embedded front cover

Compatible devices: commonly used for equipment models such as Gasonics Aura, PEP, L3510, L3512, etc

3、 Application scenarios

1. Plasma Asher/Descum equipment

Used to set process parameters (such as gas flow rate, power, temperature, time, etc.), monitor chamber status (vacuum, alarm, etc.), support operation start/stop, process selection and other functions.

2. Plasma cleaning/surface treatment equipment

The panel is used to operate the surface treatment system, achieve full control of the process, and improve user interaction efficiency.

3. Load lock control interface

As a direct control interface for the loading and unloading, vacuuming, inflation and other processes of the load lock chamber, it simplifies the operation process and avoids misoperation.

4. Laboratory/Process Development Platform

Provide local visualization and debugging functions in semiconductor experimental platforms used in R&D systems or universities/research institutes.

Product imag
