Atlas Copco PF3109-G-DN-H Controller

Atlas Copco PF3109-G-DN-H Controller

Product Details Introduction

product name

Atlas Copco PF3109-G-DN-H Controller

(Power Focus 3100 series high-performance intelligent tightening controller)

product overview

PF3109-G-DN-H is a high-power, high-performance version of the Atlas Copco Power Focus 3100 series intelligent controller.

G represents advanced functionality and graphical interface support

DN stands for built-in DeviceNet communication interface

H represents a hardware upgrade version with higher stability and scalability

This controller is used to drive and control Tensor series electric tightening tools, supporting complex multi-stage tightening strategies and real-time data monitoring, meeting the requirements of high demand industrial assembly line applications.

Main application areas

Automobile manufacturing and assembly

Precise tightening of bolts for engine, chassis, body structure, steering, and suspension systems

Workstation level program switching and MES system data integration to achieve quality traceability and error prevention management

New energy vehicles and power battery industry

Reliable tightening of battery modules, electric drive housings, and electronic control units

Ensure connection strength and controllable process to prevent missing or slipping teeth

Industrial robot automated assembly line

Robot tightening workstation control, supporting complex multi program management

Seamless communication with the main control PLC and robot control system

Manufacturing of heavy-duty equipment such as construction machinery and rail transit

Key bolt connection control of large structural components

Support remote monitoring and data tracking to meet high reliability requirements

Assembly of household appliances and electronic products

Quickly switch bolt tightening operations in flexible production lines with multiple varieties

Real time monitoring of torque and angle to ensure product quality

Product advantages

Integrated DeviceNet communication for easy connection with control systems such as Allen Bradley

Equipped with a graphical interface to simplify on-site operations and debugging

Support multi-stage torque and angle control strategies to improve assembly quality

Highly reliable data collection and traceability capabilities, meeting industrial quality standards

Compatible with multiple Tensor electric tightening tools to meet diverse assembly needs

Product imag
