Atlas Copco PF3109-C-HW Controller

Atlas Copco PF3109-C-HW Controller

Product Details Introduction

product name

Atlas Copco PF3109-C-HW Controller

(Power Focus 3100 Series High Torque Intelligent Tightening Controller)

product overview

PF3109-C-HW is a high-power control unit in the Atlas Copco Power Focus 3100 series, designed specifically for driving and controlling high torque electric tightening tools in the Tensor series. This controller supports multi-stage torque and angle control, with high-precision and high reliability tightening process control capabilities, and is widely used in industrial automated assembly lines.

Main application areas

Automobile manufacturing and final assembly

Bolt connections of key structural components such as engine, chassis, gearbox, and suspension system

Multi station program management and data traceability to achieve process stability and quality assurance

Assembly of new energy vehicles and power batteries

Assembly of high-precision torque requirements for battery modules, electric drive systems, electronic casings, etc

Support process program switching and MES system integration to ensure assembly data integrity

Industrial robot automatic tightening station

Integrate with robot systems to achieve automated and efficient bolt tightening

Support multiple industrial communication protocols for easy linkage with the main control system

Manufacturing of engineering machinery and rail transit equipment

Assembly of high torque bolts for heavy-duty structural components

Stable process control and adaptability to complex industrial environments

Manufacturing of household appliances and electrical equipment

Bolt connection of precision components, supporting quick program switching

Suitable for multi variety and small batch production environments

Product Features

Support torque, angle, and composite multi-stage control strategies

High precision torque output, excellent repeatability

Built in multiple industrial communication interfaces (optional expansion)

Support tightening data collection and quality traceability

Compatible with Tensor series multiple models of electric tightening tools

Product imag
