Tokyo Electron 2L80-004992-V2 Supply Board

Tokyo Electron 2L80-004992-V2 Supply Board

Product Details Introduction

The Tokyo Electron 2L80-004992-V2 Supply Board is a power/signal distribution module specifically designed for TEL semiconductor equipment, typically serving as a centralized supply platform for multiple power sources or signals within the system. This component is widely used in the electrical subsystems of etching, deposition, lithography and other equipment, and is an important basic unit to ensure the stable operation of the equipment.

1、 Product functional positioning

Module type: Power or Signal Supply Board

Main functions:

Branch, isolate, and stabilize the main power or signal source through this board before outputting it to each subsystem;

Implement functions such as power partition management, overcurrent protection, and signal channel switching;

It can be used in conjunction with control boards, interface boards, etc. to achieve logical control and centralized wiring.

2、 Typical application areas

1. Equipment power management system

Provide unified power supply for multiple sub modules (heaters, valve drivers, sensors, PLC boards, etc.);

Including multiple low-voltage DC power supplies such as+5V,+12V,+24V, -12V, etc.

2. Signal distribution for control and logic systems

Distribute digital/analog signals from the main controller to various functional modules;

Provide additional functions such as optocoupler isolation, signal buffering, and status indication.

3. Integration interface of process subsystem

Used to manage the power supply and interface distribution of key subsystems such as gas circuit, temperature control, liquid circuit, RF power module, etc;

It exists as a backplane or bridging platform in modular structures.

3、 Example of Adaptation Platform

Role of device platform application

TEL Unity Pro/Trias Control System Power Distribution Core

Power supply center for each submodule (gas, chamber control, power unit) of TEL Tactra/Indy series

TEL Clean Track series power/signal interface board for developing modules, heating platforms, turntables, etc
