Uniop ETOP05 touch screen panel
Product Details Introduction
UniOP ETOP05 operation interface touch screen panel
2、 Basic Function Description
ETOP05 is a graphical human-machine interface that integrates LCD display and touch control functions, designed to provide compact and reliable local control and display solutions for OEM equipment manufacturers and industrial automation users. This device is mainly used for displaying control information, alarms, parameter settings, and on-site interactive operations.
3、 Main technical parameters (typical values)
Project Description
Display screen type STN LCD, grayscale or blue white screen (depending on version)
Display resolution 320 x 240 pixels (QVGA)
Display size 5.7 inches (typical)
Backlight type: Cold cathode fluorescent lamp (CCFL)
Touch Method: Resistive Touch Screen
Communication interface 1 x RS232 serial port, 1 x RS485 (some versions)
Programmable memory Flash (capacity varies by version)
Real time clock (RTC) built-in, with battery backup
Operating voltage 24V DC (± 20%)
Installation method: Panel installation, front panel meets IP65 protection level
Working temperature: 0 ℃~50 ℃
Storage temperature -20 ℃~+60 ℃
Software supports UniOP Designer 6 or eDesigner
Product imag
