TEL Tokyo Electron 381-639094-4 Digital Input Card
- Goods status： new/used
- Delivery date: stock
- The quality assurance period： 365 days
- Phone/WhatsApp/WeChat：+86 15270269218
- Email：stodcdcs@gmail.com
- Tags：
- Get the latest price：Click to consult
TEL Tokyo Electron 381-639094-4 Digital Input Card
Product Details Introduction
TEL Tokyo Electron 381-639094-4 Digital Input Card is an electronic signal acquisition module specifically designed for TEL semiconductor equipment. It is responsible for receiving and processing digital signals from external devices, achieving functions such as status monitoring, equipment interlocking, and logic judgment during the process.
1、 Basic Information
Product Name: Digital Input Card/Digital Input Module
Product model: 381-639094-4
Manufacturer: Tokyo Electron Ltd. (TEL)
Module type: Digital input signal acquisition board (DI module)
Application scope: TEL automation process equipment such as Etcher, CVD, cleaning, Track, etc
2、 Main functions
signal acquisition
Receive switch signals (ON/OFF) from devices such as switches, sensors, relays, and photodetectors.
logical judgment
Transmit input signals to the main control system (such as PLC or industrial PC) for the judgment of equipment operation logic and process advancement.
Safety interlock support
The input signal can be used as one of the interlocking conditions for device startup, chamber locking, vacuum status confirmation, etc.
Status feedback monitoring
Monitor the actual status of key mechanisms such as door control, air valves, and robotic arms through digital inputs to ensure safe execution of the process.
3、 Typical application areas
This card is widely used in multiple core equipment systems of TEL, including:
Dry etching equipment (Etcher)
Receive gate control and vacuum in place signals, and participate in plasma start interlocking.
CVD/ALD equipment
Receive information on the opening and closing status of the reaction chamber, gas valve status, etc.
Wafer Cleaning Systems
Detect the supply status of chemical solution, pump start signal, and liquid level sensor feedback.
Photoresist processing equipment (Track System)
Receive digital feedback signals such as tray position, wafer loading, and heating module door status.
Product imag
