TEL Tokyo Electron 2981-600310-12 DC Converter Board

TEL Tokyo Electron 2981-600310-12 DC Converter Board

Product Details Introduction

Introduction to TEL Tokyo Electron 2981-600310-12 DC Converter Board

Product definition:

2981-600310-12 is a DC-DC Converter Board used to convert input DC voltage into other required voltage levels within TEL devices, providing stable multi-channel power supply.

Main functions:

Convert the main power input (such as 24V DC) into other voltage outputs (such as ± 12V,+5V, etc.) for use in internal circuits such as control boards, sensors, and communication modules.

Typical application devices:

Applied to wafer processing equipment of Tokyo Electron, such as CVD (chemical vapor deposition), Etch (etching), Clean Track (cleaning), ALD (atomic layer deposition) and other systems.

Power supply target module:

Provide stable power supply for low-voltage devices such as PLC control boards, interface boards, IO modules, sensor units, signal collectors, etc.

Product features:

Multi channel DC output (may have ± 12V,+5V, etc.)

Equipped with overvoltage, overcurrent, and short-circuit protection

High conversion efficiency, low heat generation

Modular board structure for easy installation and maintenance

Installation location:

Generally installed inside the control power rack or main control cabinet, close to the main control power output area or IO distribution board.

Application scenarios:

Power supply for circuit boards with different logic level requirements in precision control systems

Provide isolated power supply for photoelectric sensors, display screens, controllers, etc

Plays a role in isolating power supply voltage, suppressing interference, and improving equipment electrical safety

Product imag
