EATON PL9-C2-2 Miniature Circuit Breaker

EATON PL9-C2-2 Miniature Circuit Breaker

Product Details Introduction

EATON PL9-C2-2 miniature circuit breaker is a modular circuit breaker produced by Eaton Corporation for use in low-voltage distribution systems, with high reliability and good overload and short-circuit protection performance. The following is an overview of its products and an introduction to its application areas:

1、 Basic Product Information

Model: PL9-C2-2

Type: Miniature Circuit Breaker (MCB)

Number of poles: 2 poles (bipolar)

Rated current: 2 A

Release curve: C-type (C Curve, suitable for conventional resistive and mild inductive loads)

Rated voltage: generally 230/400V AC (depending on regional standards)

Breaking capacity: usually 6kA (to be confirmed with specific series)

Installation method: DIN rail installation

Compliant with standard: IEC/EN 60898-1

2、 Product Features

Provide bipolar isolation protection, which can be used for simultaneous disconnection of dual line systems

Quick disconnect mechanism, which can quickly cut off the power supply in case of overcurrent or short circuit

Compact size, suitable for standard electrical distribution boxes

C-type trip characteristic, suitable for electric motors, small transformers, and lighting loads

High mechanical and electrical lifespan, suitable for frequent operation

Product imag
