B&R 4E0011.01-090 Button Panel

B&R 4E0011.01-090 Button Panel

Product Details Introduction

Basic information

Product model: 4E0011.01-090

Brand: B&R (Bernecker&Rainer)

Product Type: Button Panel Module/Extended Operation Panel

Function definition: Used as a local input device for HMI (Human Machine Interface) or control station in industrial automation systems

Main technical parameters

Number of buttons: A typical configuration consists of 16 functional buttons (depending on the version)

Button type:

Industrial machinery buttons with tactile feedback

Insertable tags to customize feature descriptions

Most buttons support backlighting (optional)

Interface type:

Dedicated B&R interface (connected to the main control through internal connection or bus system)

Generally does not come with standard communication ports, such as RS232/USB

Power supply mode: Powered by the main control unit (such as Power Panel, Automation Panel)

Protection level: Front support IP65 (dustproof, waterproof, suitable for industrial sites)

Installation method: Embedded installation on the front panel, requiring control cabinet or console openings

Model suffix description

'. 01' indicates hardware version

-090 "represents customized configuration by the customer (which may include personalized customization of button arrangement, icons, colors, and interface layout)

Application scenarios

Human Computer Interaction Interface for B&R Automation Control System

Local control units for industrial equipment, such as:

Packaging machine control panel

Production line start/stop panel

CNC、 Local manual control panel for robots and other devices

Used in conjunction with HMI or PLC for on-site operation button area

Product imag
