Product Details Introduction

Product model: IC693MDL655K

Product type: 24V DC discrete input module (dry contact)

Series: GE Fanuc Series 90-30 PLC Series

Input points: 32 input points

Signal type: DC signal, suitable for switch input (ON/OFF)

Technical Parameter

Rated input voltage: 24V DC

Voltage range: 0-30V DC

Logic level:

ON state voltage ≥ 15V DC

OFF state voltage ≤ 5V DC

Input current per point: typical value is 7 mA @ 24V DC

Response time:

ON delay:<7 ms

OFF delay:<7 ms

Common port type: Multiple shared ports, grouped by 16 points, with a total of two groups

Module structure and installation

Module installation location: Installed in Series 90-30 rack, supports hot swapping

Wiring method: Using detachable terminal blocks for easy wiring and replacement

Insulation isolation: Input and PLC internal circuit isolation to enhance system stability

Indicator lights: Each input point is equipped with an LED status indicator light

application area

Digital signal acquisition of industrial production line equipment

Switching control system (such as buttons, limit switches)

Automation control in industries such as chemical, power, metallurgy, and packaging

Build a complete control system in conjunction with other GE 90-30 series modules

Product imag
