Siemens 6EP1437-3BA00 power module

Siemens 6EP1437-3BA00 power module

Product Details Introduction

Siemens 6EP1437-3BA00 is a high-performance power module in the Siemens SITOP series, belonging to the SITOP PSU8600 intelligent power system. This power supply is designed specifically for industrial automation systems, with extremely high reliability and communication capabilities. It supports integration with upper control systems through PROFINET and is suitable for industrial applications that require high levels of power intelligence, diagnosability, and redundancy.

1、 Basic Information

Project Content

Brand Siemens Siemens

Series SITOP PSU8600

Product model 6EP1437-3BA00

Product Name: Power Supply Unit

Output type: Programmable DC power output

Installation method: DIN rail installation

Communication interfaces PROFINET, USB, OPC UA (via extension)

2、 Technical specifications and parameters

Parameter values

Input voltage AC 400-500 V (three-phase)

Input frequency 50/60 Hz

Output voltage 24 V DC (adjustable range: 22-28 V)

Maximum output current of 40 A

Rated output power 960 W (24 V × 40 A)

Efficiency ≥ 94%

Insulation protection level Class I (grounding protection)

Communication interface PROFINET (supporting S7 and TIA Portal integration)

Working temperature -25 ° C~+70 ° C

Cooling method: natural ventilation

Size 145 × 125 × 150 mm (height × width × depth)

Certification standards such as CE, UL, CSA, EN 61010, etc

3、 Function and Features

✅  Multi output intelligent control: supports multi-channel output (requires module expansion), can independently control and set;

✅  PROFINET communication integration: realizing remote monitoring, diagnosis, and parameter setting of power supply;

✅  High availability design: supports parallel redundancy of power supplies to enhance system stability;

✅  Support voltage/current limit protection: prevent downstream equipment from short circuit and overcurrent;

✅  Support energy monitoring: can collect current power consumption, voltage, current and other parameters and upload them to the system;

✅  Plug and play scalability: It can be connected to modules to expand more output, communication, or UPS functions.

Product imag
