CI810B 3BSE020520R1 Controller Module

CI810B 3BSE020520R1 Controller Module

Product Details Introduction

The ABB CI810B 3BSE020520R1 controller module is a communication interface module used in ABB control systems for industrial automation and process control. It is commonly used as a communication bridge between S800 I/O modules and main controllers (such as AC 800M) and supports the PROFIBUS DP protocol.

1、 Basic Product Information

Project Content

Product Name: Communication Interface Module

Model CI810B

Order number 3BSE020520R1

Brand ABB

System Platform AC 800M Control System, S800 I/O Series

Communication protocol PROFIBUS DP Slave

2、 Function and Features

PROFIBUS DP interface

The module is connected to the PROFIBUS network as a slave station;

Allow AC 800M controller to communicate with remote S800 I/O module via PROFIBUS.

Hot swappable support

Can be replaced during system operation without power outage;

Improve system maintainability and operational continuity.

Module redundancy support

Can be redundantly configured with another CI810B;

Automatically switch in case of main module failure to ensure uninterrupted communication.

Integrated diagnostic function

Equipped with status LED indication;

Support system internal diagnosis and alarm management.

3、 Technical specifications and parameters

Project parameters

Communication type PROFIBUS DP (RS-485)

From station address range 0-125

Maximum baud rate of 12 Mbps

Supply voltage 24 V DC (powered through S800 I/O connector)

Power consumption is about 1.5 W

Interface type 9-pin SUB-D (DP interface)

Working temperature range -25 ° C to+70 ° C

Installation method: DIN rail, plug into S800 I/O base

Compatible with base modules TU810, TU812, TU830, TU833, etc

Product imag
