Siemens 6SE6440-2AD25-5CA1 frequency converter

Siemens 6SE6440-2AD25-5CA1 frequency converter

Product Details Introduction

Siemens 6SE6440-2AD25-5CA1 is a high-performance frequency converter from Siemens MICROMASTER 440 series, used to regulate the speed of three-phase AC motors, especially suitable for industrial automation applications that require high dynamic performance and process control.

1、 Basic Information

Project Description

Product model 6SE6440-2AD25-5CA1

Series MICROMASTER 440

Brand Siemens

Product type: Frequency Inverter/AC Drive

Output power of 15 kW (approximately 20 HP)

The maximum output current is about 31 A (depending on the load)

Input voltage 3AC 380~480V ± 10%

Input frequency 47-63 Hz

Cooling method: Air cooling (built-in fan)

2、 Functional Features

High Performance Vector Control (VC) and V/f Control

Supports sensorless vector control and standard V/f control;

Closed loop control can be selected (through optional encoder) to achieve more accurate speed control.

Rapid braking capability

Built in brake chopper, can be connected to external brake resistors;

Suitable for fast stopping scenarios with high inertia loads, such as elevators and cranes.

Rich protection functions

Undervoltage, overvoltage, overload, overheating, grounding fault, short circuit protection;

Motor overheating monitoring.

Flexible communication and expansion capabilities

Supports USS and Modbus RTU communication protocols;

Optional modules such as PROFIBUS, CANopen, DeviceNet, etc.

User friendly debugging interface

Support BOP (Basic Operations Panel) and AOP (Advanced Operations Panel);

Debugging and parameter settings can be performed through PC software STARTER or MICROMASTER Shell.

Multi functional I/O interface

Flexible configuration of digital input, digital output, and analog input/output;

Multiple sensors, switch values, and controllers can be connected.

Product imag
