TRICONEX DO2401 7400209-030 Digital Output Base

TRICONEX DO2401 7400209-030 Digital Output Base

Product Details Introduction

Model: TRICONEX DO2401

Part number: 7400209-030

Type: Digital Output Baseplate Module

product positioning

DO2401 is a base module used for digital output signal connection in the Triconex system, specifically designed to provide hardware connection interfaces for digital output modules such as DO3401. It transmits the output signals of the control system to on-site devices such as relays, solenoid valves, contactors, etc. through wiring terminals.

central role

Provide physical installation interface and on-site wiring terminals for DO3401 digital output module

Connect the module to external loads such as solenoid valves, relays, etc

Provide electrical isolation and fault protection for output channels

Helps achieve seamless integration when maintaining and replacing output modules

Technical Parameter

Adaptation module: Triconex DO3401 digital output module

Number of channels: 32 digital output channels (each channel is independent)

Output voltage: 24 VDC (external power supply)

Load type: Suitable for inductive or resistive loads

Installation method: DIN rail or rack installation

Wiring method: Screw crimping terminal (independent wiring for each channel)

Isolation design: The output channel is electrically isolated from the system bus to enhance anti-interference performance

Protection function: equipped with overcurrent protection, short circuit protection, ground fault protection, etc

Module Features

High reliability: compatible with Tricon triple redundant control system, supporting high availability requirements.

Simple structure: modular design, easy to install and maintain.

Status display: Some versions support LED indicator lights to display channel output status (requires coordination with upper level modules)

Hot swappable support: Supports online module replacement without interrupting system operation.

Strong anti-interference ability: Electrical isolation protection, suitable for industrial sites with complex electromagnetic environments.

Product imag
