TRICONEX DI2301 7400208-020 Connection Module

TRICONEX DI2301 7400208-020 Connection Module

Product Details Introduction

TRICONEX DI2301 Digital Input Connection Module

Part number: 7400208-020

product type

Digital input module, commonly used in Triconex systems, is responsible for receiving digital input signals from field devices and transmitting them to the control system.

major function

Receive digital signals from on-site devices such as limit switches, buttons, proximity switches, etc.

Send these signals to the Triconex control system for further processing.

Equipped with powerful signal isolation function, ensuring the accuracy and stability of signals.

Technical Parameter

Input points: 32 single ended inputs or 16 differential inputs

Input voltage: 24 VDC (common configuration)

Input type: Supports wet contact and dry contact input

Response time: Meet the needs of most industrial control applications

Electrical isolation: The input channel is electrically isolated from the system side to enhance anti-interference capability

Working temperature range: -40 ℃ to 70 ℃

Storage temperature range: -40 ℃ to 85 ℃

Humidity range: 5% to 95% (without condensation)

Module Features

High reliability: capable of supporting redundant system architecture, ensuring reliable input in case of failure.

Multiple input modes: Supports single ended input and differential input, compatible with various field devices.

Electrical isolation: There is isolation between the input terminal and the control system to ensure system stability.

Filtering function: Built in signal filtering reduces noise interference and improves signal accuracy.

Easy to maintain: The module has status indicator lights for easy troubleshooting and diagnosis.

Product imag
