TRICONEX CM2201 7400206-100 Communication Module

TRICONEX CM2201 7400206-100 Communication Module

Product Details Introduction

Product Name: Triconex CM2201 Communication Module

Part number: 7400206-100

Product type: Communication Module or Communication Interface Module

System: Triconex Safety Instrumented System (SIS)

Manufacturer: Triconex brand under Schneider Electric

1、 Function Overview

The CM2201 module is the core communication module of the Tricon control system, responsible for communication with the upper computer system, third-party control system, and redundant controllers. Commonly used for critical operations such as system level data synchronization, status monitoring, and data forwarding.

2、 Main technical parameters

Communication interface: serial port, Ethernet (depending on specific configuration)

Bus type: Used for Tricon rack communication slots

Communication protocol support: Supports Modbus, OPC, TCP/IP, UDP, Triconex peer-to-peer communication, etc

Applicable configuration: support communication synchronization in TMR (the third mock examination Redundancy) architecture

Working voltage: Powered by the main system, no external independent power supply is required

Working temperature: 0 ℃ to 60 ℃

Storage temperature: -40 ℃ to 85 ℃

Humidity range: 10% to 90% without condensation

Module hot swappable: Supports

Product imag
