Siemens C79298-A3220-B105 Four Axis Dimensioner/Driver Module

Siemens C79298-A3220-B105 Four Axis Dimensioner/Driver Module

Product Introduction

Siemens C79298-A3220-B105 Four Axis Dimensioner/Driver Module

Product Features:

1. Support four axis synchronous indexing positioning, high precision of angle control, and smooth start stop response

2. Equipped with closed-loop position feedback, it can correct the division deviation in real time and has good positioning repeatability

3. Compatible with Siemens industrial control bus, stable instruction reception, and supports upper computer program control

4. Built in overload and overcurrent protection to reduce the risk of damage to the motor and transmission mechanism

5. Original electrical specifications, interface matching, and machine maintenance can be directly replaced

Application fields:

1. Semiconductor wafer indexing and rotating station drive

2. Four axis positioning control of optical detection turntable

3. Precision automation indexing tool drive

4. Motion control of vacuum equipment rotating stage

5. Multi station rotating switching mechanism on the production line

6. Maintenance of spare parts for Siemens automation equipment

7. Precision testing equipment upgrade and renovation project

8. Multi angle observation and rotation control of sample stage

9. Non standard automated rotating mechanism matching

10. Precision assembly indexing station drive

The Siemens C79298-A3220-B105 quadcopter/driver module is a core spare part for achieving precise indexing drive in multi axis rotary positioning mechanisms

Product imag
