JEOL AP002108 (00) Video Control PCB Card

JEOL AP002108 (00) Video Control PCB Card

Product Introduction

JEOL AP002108 (00) Video Control PCB Card

Product Features

1. Developed specifically for JEOL electron microscopes, responsible for electronic image signal conversion and video output control.

2. The signal gain and contrast are hardware adjustable, allowing for real-time optimization of the quality of microscopic images.

3. Onboard signal denoising circuit to reduce image noise interference caused by high voltage inside the electron microscope.

4. Synchronize multi-channel video signal output to match the image display and storage unit of the electron microscope host.

5. Adapt to JEOL device backplane slots, directly replace installation, and shorten equipment downtime for maintenance.

Product application areas

1. Scanning electron microscope SEM video image control unit

2. Transmission electron microscope TEM image signal processing board

3. Semiconductor defect detection electron microscope image output module

4. Microscopic morphology observation of materials, electron microscope video control component

5. Electron microscope image acquisition and control system for metal fracture analysis

6. Failure Analysis Laboratory Electron Microscope Display Driver Unit

7. Maintenance spare parts for electron microscopes in university material characterization laboratories

8. Industrial quality inspection electron microscope maintenance and replacement project

9. Transformation of Microscopic Analysis Equipment Image System in Research Institutes

10. JEOL series electron microscope complete machine matching image control module

This PCB card is a core video processing spare for JEOL electron microscopy, which processes electron beam imaging signals and outputs visualized images to ensure stable and clear microscopic observation images
