Rigaku A932-28-1D (4) Control Circuit Board

Rigaku A932-28-1D (4) Control Circuit Board

Product Introduction

Rigaku A932-28-1D (4) Control Circuit Board

Product Features

1. Adapt to a 3kW X-ray generator unit in science, responsible for X-ray source start stop and power closed-loop control.

2. Multiple signal interaction channels, linked with high-voltage power supply, water cooling, and safety interlock protection circuits.

3. Onboard hardware fault monitoring, capable of real-time reporting of high voltage anomalies, temperature, and interlock alarm signals.

4. Special PCB anti-interference wiring to resist high-voltage electromagnetic noise interference inside X-ray equipment.

5. Native matching with Rigaku instrument backplane interface, direct replacement, easy and fast device debugging.

Product application areas

1. Physical XRD diffractometer X-ray generator interface control board

2.3kW X-ray tube high-voltage power supply linkage control system

3. XRF fluorescence spectrometer radiation source safety interlock unit

4. Thin film X-ray reflection testing equipment - Radiation source control component

5. Main control board for metal residual stress detection X-ray instrument

6. High voltage control module for powder crystal phase analysis instrument

7. X-ray equipment for characterizing the crystal orientation of semiconductor materials

8. Maintenance spare parts for XRD instruments in university material laboratories

9. Industrial quality inspection X-ray analysis equipment maintenance and replacement project

10. Upgrading and renovating outdated X-ray diffraction equipment in science

This circuit board is a specialized interface control spare for Rigaku X-ray instruments, which controls the output of X-ray generators and safety interlocks, ensuring the stable and safe operation of X-ray analysis equipment

Product imag
