Coreco XR-M130-10801 Image Acquisition Card

Coreco XR-M130-10801 Image Acquisition Card

Product Introduction

The Coreco XR-M130-10801 image acquisition card is an industrial machine vision ISA bus image acquisition board, responsible for digital conversion and image transmission of industrial camera image signals, and adapting to old automated visual inspection equipment

Product Features

High speed acquisition of analog image signals with low screen acquisition delay

Hardware real-time image preprocessing, reducing image noise and improving image quality

Onboard signal protection circuit to resist on-site electromagnetic interference

ISA bus slot design, suitable for installation on old industrial control hosts

Equipped with status monitoring, quickly locate image acquisition link faults

Application Fields

Semiconductor Device Visual Inspection System

Electronic component appearance inspection equipment

PCB circuit board image acquisition unit

Precision component dimension visual measurement device

Industrial microscope image acquisition equipment

Wafer appearance defect detection equipment

Visual inspection device for printing quality

Packaging appearance defect inspection equipment

Research Microscopic Image Acquisition System

Old style automated visual industrial control equipment

Product Specifications

Internal DC power supply of industrial control chassis, stable and reliable power supply

Continuous operation of control cabinet in the conventional industrial temperature range

Using ISA bus and industrial control host to complete data communication

The Coreco XR-M130-10801 image acquisition card, as a core spare part for old visual equipment, completes image signal acquisition and digital processing, and is commonly used for repairing and replacing old semiconductor and industrial visual inspection equipment

Product imag
