AE 3155132-010 High Current RF Matching Navigator

AE 3155132-010 High Current RF Matching Navigator

 Introduction

AE 3155132-010 high current RF matching navigator, AE Navigator series RF matching module, compatible with AMAT semiconductor machines, used for automatic matching of cavity impedance.

Product Features

1. Fast tuning response, the cavity impedance can quickly keep up with changes

2. Supports high current operating conditions, with low loss in high-power RF transmission

3. Real time monitoring of reflected power, automatic protection of RF source in case of abnormalities

4. High matching accuracy ensures consistency in the wafer process for each batch

5. Strong anti-interference ability, stable operation in complex electromagnetic environment of dust-free workshop

6. High temperature and vibration resistance, suitable for long-term uninterrupted operation of production lines

7. Smooth communication with the host, reporting matching operating status at any time

8. Modular design, easy disassembly and replacement, reducing downtime

9. Built in process parameter memory, no need to repeatedly debug when switching processes

10. Solid internal components and low continuous production failure rate

Application Areas

1. AMAT plasma etching machine

2. Semiconductor thin film deposition equipment

3. Plasma surface treatment of wafers

4. Dry etching process chamber

5. Semiconductor high-power RF process system

AE 3155132-010 high current RF matching navigator has sensitive tuning and stable high current operating conditions, making it a core RF matching spare part in AMAT machines.

Product imag
