 Introduction

REXROTH HMS01.1N-W0070-A-07-NNN servo driver

This REXROTH HMS01.1N-W0070-A-07-NNN is a Rexroth IndraDrive M series single axis servo inverter that relies on DC bus power supply to drive servo motors for high-precision motion control.

Rexroth modular single axis servo drive unit

Receive instructions from the upper controller and output adjustable frequency voltage to drive the motor

Built in cooling fan with multiple protection functions such as overload and overvoltage

Support multiple encoder signal access, fast closed-loop positioning response

Adopting IP20 protective cabinet installation structure, suitable for multi axis combination matching

The selection must be checked for the complete model code, and different parameters cannot be directly replaced

Before dismantling and maintenance, disconnect the DC bus and wait for the capacitor to discharge before operating

Before powering on, check the power cables and feedback lines, and ensure proper grounding to suppress electromagnetic interference

Long term storage in a dry and dust-free environment to avoid moisture and aging of power devices

Application

Machine tool feed axis servo drive matching

Transformation of Multi axis Positioning System in Automated Production Line

Replacement of motion control unit for metal processing equipment

High precision transmission control of printing machinery

Replacement of complete modular servo system spare parts

REXROTH HMS01.1N-W0070-A-07-NNN servo driver is used for speed, position, and torque control of single axis servo motors.

Product imag
