RENISHAW ACC2-2 Automatic Conversion Control Unit
- Goods status： new/used
- Delivery date: stock
- The quality assurance period： 365 days
- Phone/WhatsApp/WeChat：+86 15270269218
- Email：stodcdcs@gmail.com
- Tags：ACC2-2
- Get the latest price：Click to consult
RENISHAW ACC2-2 Automatic Conversion Control Unit
Introduction
RENISHAW ACC2-2 Automatic Conversion Control Unit
This RENISHAW ACC2-2 automatic conversion control unit is a dedicated controller for the three coordinate measuring machine probe exchange rack, used to control the automatic needle exchange process of ACR1.
Renishaw old CMM probe automatic exchange controller
Establish a communication link between the three coordinate host and ACR1 exchange rack
Complete the multiplexing and transmission of signals for the measuring seat and measuring needle
Equipped with RS232 and IEEE dual communication interfaces to adapt to early measurement hosts
Built in exchange timing logic, automatically executes needle picking and putting back actions
Sensitive to fluctuations in power supply voltage and requiring a stable AC power supply environment
Selection matching requires checking the equipment model, and the old and new versions cannot be directly replaced
Before wiring operations, disconnect the power supply of the equipment and take measures to protect against static electricity
Confirm the communication baud rate before powering on and test the rack switching action
Long term storage to prevent dust and moisture, avoiding oxidation of interface pins
Application
Three coordinate measuring machine ACR1 measuring needle exchange rack matching
Precision testing equipment probe automatic replacement system maintenance
Upgrading and renovating the three coordinate equipment in the metrology laboratory
Signal interaction matching for workpiece detection and measurement system
Replacement of old CMM equipment spare parts
The RENISHAW ACC2-2 automatic conversion control unit is responsible for the timing control and signal communication of the automatic exchange of measuring needles in the three coordinate equipment.
Product imag
