MITSUBISHI D65UB004431 HR371-Y Input/Output Interface Board

MITSUBISHI D65UB004431 HR371-Y Input/Output Interface Board

 Introduction

Let me introduce the MITSUBISHI D65UB004431 HR371-Y input/output interface board, which belongs to the Mitsubishi CNC system I/O board and is often used for machine tool maintenance and replacement

Product Features

Compatible with Mitsubishi MELDAS CNC system, responsible for machine tool signal acquisition and output

Onboard optoelectronic isolation design can reduce on-site electrical interference

Source type output circuit, stable docking with various machine tool sensors and solenoid valves

Compact board layout, directly installed in the slot of the CNC cabinet

Original factory standard pin definition, fault replacement installation without changing the circuit

Product Specifications

Model D65UB004431 HR371-Y CNC I/O board

Comes with 16 point input and 16 point output channels

Supports DC 24V and DC 5V power supply

Communication between CF30 interface and CNC host

Working temperature adaptation for machine tool control cabinets in conventional industrial environments

Application Areas

Signal interaction control of CNC machining machine tools

CNC equipment maintenance and replacement spare parts

Lathe milling machine IO signal acquisition and output

Automated machine tool transformation supporting board

Docking of peripheral solenoid valve sensors for CNC equipment

Overall, this Mitsubishi HR371-Y interface board is a crucial signal accessory for old CNC equipment, with stable signal transmission and high practicality for replacing machine parts

Product imag
