AMAT 0100-35174 Matrix PCB Board

AMAT 0100-35174 Matrix PCB Board

 Introduction

AMAT 0100-35174 Matrix PCB Board

Product Features

1. Stable signal transmission, reliable switching of multi-channel matrix signals

2. Strong anti-interference ability suitable for complex electromagnetic environments in semiconductor cabinets

High integration of 3 boards saves internal installation space of equipment

4 interface matching original equipment can be directly replaced without changing the circuit

5. Durable workmanship that can run continuously for a long time without easily malfunctioning

Product Specifications

1. Compatible with semiconductor equipment cabinet standard power supply

2 multi-channel matrix signal input and output

3 industrial grade working temperature range to adapt to cabinet temperature rise

4 original factory standard interfaces for quick integration with the main control system

The insulation performance of the 5-layer board process circuit is good

Application Areas

1. Semiconductor process equipment signal matrix control

Transfer of main control signals for wafer processing equipment

3 PVD thin film deposition equipment signal acquisition board

4. Multi channel signal distribution for vacuum process equipment

5. Replacement of old boards and spare parts for application materials and equipment

This AMAT 0100-35174 matrix PCB board belongs to the semiconductor original factory board and is often used for equipment maintenance and replacement

Product imag
