Astrodyne E19339940 analyzer calibrator

Astrodyne E19339940 analyzer calibrator

 Introduction

AE 3152194-008 DC power board

Product Features

Stable output voltage provides continuous and reliable power supply to the equipment

2. Equipped with overvoltage and overcurrent protection, it automatically shuts off in case of abnormal operation

3 Strong anti-interference capabilities suitable for electromagnetic environments in semiconductor cabinets

4. The original factory matching of the board interface can be directly replaced without changing the wiring

5. Simple structure, fast disassembly and replacement speed

Product Specifications

1. Adapt to device AC input power supply

2 channels of DC voltage stabilization output

3 Industrial grade temperature resistant and adaptable cabinets with internal temperature rise

4. Comes with signal feedback to report power status

5. Reliable insulation protection for multi-layer circuit boards

Application Areas

1. Main control board for power supply of semiconductor sputtering equipment

2 Vacuum Coating DC Power Supply Supporting Board

3 PVD process equipment power supply control unit

Internal components of plasma process power supply

5 AE power supply maintenance spare parts replacement

This AE 3152194-008 DC power board is a commonly used board for Pinnacle series power supplies, mainly used for semiconductor power supply maintenance and replacement

Product imag
