AMAT 0190-00899 Interface PCB Card

AMAT 0190-00899 Interface PCB Card

 Introduction

The AMAT 0190-00899 interface PCB card is a cavity signal adapter board for application material machines, responsible for signal communication between the host and cavity components.

Product Features

Stable signal transmission ensures synchronization of cavity process actions.

The board is equipped with a filtering circuit to resist electromagnetic interference in the RF environment.

Standard slot structure, easy to repair, replace, disassemble and assemble.

Long term operation in clean workshops, resistant to environmental precipitation pollution.

Centralized transfer of multiple signals to simplify internal wiring.

Product Specifications

Model 0190-00899 interface PCB.

Compatible with AMAT Centura series process machines.

Logic 5V, on-site signal 24V DC power supply.

Multiple digital signal inputs and outputs.

Original factory cable interface, directly plug in for use.

Application Areas

Semiconductor etching cavity signal conversion.

I/O signal interaction of thin film deposition equipment.

AMAT old machine spare parts maintenance and replacement.

Collection of cavity safety interlock signals.

Communication between wafer process equipment subunits.

This PCB is the signal bridge between the cavity and the main control, and it is often prioritized for troubleshooting when the machine signal is abnormal.

Product imag
