AE 3155132-001 RF Matching Module

AE 3155132-001 RF Matching Module

 Introduction

Colleagues who do semiconductor RF maintenance are familiar with AE 3155132-001 RF matching module. This AE Navigator series matching module is used to automatically adjust load impedance, reduce RF reflection, stabilize plasma, and is a key RF matching spare part in etching equipment.

Product Features

1. Quick automatic tuning response, quickly completing impedance matching when plasma load changes

2. Strong anti-interference ability, stable operation even in complex electromagnetic environments in the workshop

3. Built in multiple protections, automatically protect the RF power supply when the reflected power exceeds the standard or overheats

4. Original interface design, smooth communication with the matching RF generator, and easy on-site replacement

5. The module structure is compact and suitable for installation in the narrow RF compartment of the machine

Product Specifications

1. Operating frequency 13.56MHz

2. Compatible with a maximum RF power of 5500W

3. Standard system impedance 50 Ω

4. Power supply 24VDC

5. Support digital communication, real-time feedback of matching status and alarm information

Application Areas

1. Dry etching process for semiconductor wafers

2. Plasma thin film deposition process

3. Plasma surface cleaning process for wafers

4. RF impedance matching of plasma processing chamber

5. Maintenance and replacement of spare parts for AE RF system

Overall, the AE 3155132-001 RF matching module has a fast matching speed and can effectively reduce power reflection. It is commonly used for replacing RF circuit faults in etching production lines.

Product imag
