 Introduction

Most colleagues in the semiconductor high-voltage power supply maintenance industry are familiar with the HiTek E19306280 power module. This HiTek high-voltage power module is specifically designed to power ion implantation machines with stable output voltage and is a critical power supply spare part in the machine.

Product Features

1. The output voltage is stable, and there will be no significant voltage drift even when the load fluctuates

2. Multiple protection design, overvoltage, overcurrent, and overheating will trigger protection to avoid damaging the machine

3. Strong resistance to electromagnetic interference, suitable for the complex electromagnetic environment of semiconductor workshops

4. Original standard interface, directly disassembled and assembled on site, reducing downtime for maintenance

5. The internal components are durable and suitable for long-term uninterrupted continuous operation of the machine platform

Product Specifications

1. Input voltage: 24VDC

2. High voltage output can reach up to 30kV

3. Maximum output current of 5mA

4. Working environment temperature: 5 ℃~40 ℃

5. Support fault signal feedback to the machine system

Application Areas

1. High voltage power supply for semiconductor ion implantation machine

2. High voltage circuit matching for wafer doping process

3. Ion source system power supply drive

4. High voltage unit of precision vacuum equipment

5. Replacement and maintenance of spare parts for ion implantation equipment

In general, the HiTek E19306280 power module has stable high-voltage output and a complete protection mechanism. It is often used for replacing ion implantation machine power supply faults.

Product imag
