CTI Kryogenics 8185156G001 Catheter Input Module

CTI Kryogenics 8185156G001 Catheter Input Module

 Introduction

Colleagues who repair low-temperature cold pumps are generally familiar with the CTI Kryogenics 8185156G001 conduit input module, also known as the CIM pre cooling module, which is a core spare part for cold head matching. It is responsible for refrigerant transportation and signal acquisition, ensuring the stable operation of low-temperature vacuum systems.

Product Features

1. Stable refrigerant transportation ensures the pre cooling effect of the cold head and quickly lowers the chamber temperature

2. Integrated sensor acquisition, real-time monitoring of pipeline status, and timely feedback of abnormal signals

3. Reliable sealing performance, reducing the risk of refrigerant leakage, and adapting to high vacuum conditions

4. Original matching interface, easy on-site disassembly and assembly, shortening production line downtime for maintenance

5. Low temperature resistant design, maintaining stable working conditions even under low temperature conditions

Product Specifications

1. Compatible with CTI low-temperature cold head, with pre cooling integrated structure

2. Support refrigerant pipeline transmission and multi-channel signal acquisition

3. Adapt to the working environment of semiconductor cleanrooms

4. Comes with pipeline sealing components, resistant to low-temperature deformation

5. Real time status data can be uploaded to the machine controller

Application Areas

1. Low temperature cold pump matching for semiconductor equipment

2. Construction of low-temperature pre cooling system for vacuum chamber

3. Vacuum unit maintenance of wafer etching equipment

4. High vacuum cold head matching for thin film deposition equipment

5. Replacement and maintenance of spare parts for CTI cold pump equipment

Overall, the CTI Kryogenics 8185156G001 conduit input module is a critical component in the cold pump system, combining refrigerant piping and signal monitoring. It is frequently used for cold pump replacement in case of malfunctions.

Product imag
