Nikon 4S025-569 driver PCB card

Nikon 4S025-569 driver PCB card

 Introduction

Nikon 4S025-569 is an ACP-420 driver PCB card, compatible with NSR-S620D immersion lithography machine, responsible for optical unit drive control.

1. Output high-speed driving signals to control the actions of the optical execution components of the machine;

2. Equipped with signal filtering to reduce electromagnetic interference in the optical drive circuit;

3. Real time collection of driver load status, triggering fault alarms in case of abnormalities;

4. Standard CPCI slot board, easy to replace and maintain;

5. Support high-speed data exchange with the main control board.

1. Card alias ACP-420;

2. Compatible model NSR-S620D;

3. Board type driver PCB;

4. Bus CPCI;

5. Working environment inside the cabinet.

1. Optical component drive signal output of lithography machine;

2. Exposure light path fine adjustment mechanism control;

3. Monitoring the load status of optical units;

4. Signal transmission of optical drive circuit;

5. Immersion lithography machine optical drive unit.

This 4S025-569 is a lithography machine optical system driver board, which directly affects the stability of optical path adjustment.

Product imag
