Nikon 4S015-499-FP Single Board Computer

Nikon 4S015-499-FP Single Board Computer

 Introduction

Nikon 4S015-499-FP is a lithography machine SBC single board computer responsible for subsystem operations and data processing.

1. Onboard processor, capable of independently running local control programs;

2. Integrate storage units to store process parameters and operation logs;

3. Multi channel bus, connecting various boards of the machine to transmit data;

4. It comes with a built-in fault self check and outputs an alarm message in case of abnormalities;

5. Slot type PCB board, directly installed into the lithography machine cabinet.

1. Type: SBC single board computer;

2. Adaptation: NSR series stepper scanning lithography machine;

3. Interface: Internal dedicated high-speed bus;

4. Installation: Standard slot card;

5. Working temperature: 5-40 ℃.

1. Lithography machine subtask data calculation and processing;

2. Storage and retrieval of local process parameters;

3. Data transfer between various functional boards;

4. Collection of device operation log records;

5. Lithography equipment subsystem control unit.

This 4S015-499-FP belongs to the embedded computing board of the lithography machine, which shares the computing pressure of the host

Product imag
