Nikon 4S066-590-2 amplifier module

Nikon 4S066-590-2 amplifier module

 Introduction

The Nikon 4S066-590-2 is a servo amplifier module specifically designed for Nikon lithography machines, responsible for driving the internal precision actuators of the machine to ensure smooth and controllable lithography scanning actions.

1. Multi channel signal synchronous output, which can cooperate with multiple groups of motors to ensure consistent scanning motion timing;

2. Equipped with real-time status acquisition function, continuously monitoring current and temperature, and capturing abnormal working conditions in advance;

3. The board comes with a built-in filtering circuit to reduce the interference of electromagnetic noise inside the machine on precision control signals;

4. Support fast fault code feedback, which can quickly locate the fault point of the amplifier itself during maintenance;

5. Compact board layout, suitable for the narrow cabinet space of lithography machines, easy to replace and disassemble.

6. Drive object: precision linear motor;

7. Feedback signal: closed loop of grating position signal;

8. Working power supply: DC48V;

9. Signal bus: dedicated high-speed communication within the device;

10. Compatible models: NSR series stepper scanning lithography machine;

11. Linear motor drive control for lithography mask stage;

12. Multi axis synchronous motion during exposure scanning stage;

13. Precise alignment and fine adjustment drive for mask plate;

14. Closed loop adjustment of the position of the motion axis of the lithography equipment;

15. High end lithography equipment precision servo control unit.

This 4S066-590-2 is a core spare part for the motion control of the lithography machine, which plays a crucial role in the alignment accuracy of the mask stage
