NSK ESA-B014CF7-11 servo motor drive module

NSK ESA-B014CF7-11 servo motor drive module

 Introduction

NSK ESA-B014CF7-11 is a precision compact servo motor drive module, commonly used for precise driving of small linear motors in semiconductor equipment.

1. Adopting lightweight closed-loop control, low-speed operation without vibration, excellent performance in small displacement control;

2. Built in multiple fault protection, overcurrent, overload, and encoder abnormalities will quickly trigger alarms;

3. Miniaturized board card design, occupying less cabinet space and adapting to compact machine layouts;

4. Support storage of multiple motion parameters, facilitating quick switching between different motion process schemes;

5. Optimization of anti-interference circuits for stable operation in complex electromagnetic environments of semiconductor devices.

1. Suitable for motor rated power of 140W;

2. Control mode: Dual mode of position/speed;

3. Input power supply DC24V;

4. The encoder signal supports differential input;

5. The communication protocol is compatible with the device specific bus.

1. Drive the semiconductor wafer stage fine-tuning mechanism;

2. Precise positioning slide control of optical detection equipment;

3. Motion control of the micro leveling axis inside the lithography machine;

4. Drive the small linear actuator unit inside the vacuum equipment;

5. Precision measuring equipment with servo control for micro displacement platform.

This ESA-B014CF7-11 is skilled in small stroke high-precision motion and is a commonly used small servo drive spare part in semiconductor precision equipment

Product imag
