Leybold 400035V0011 Digital Controller

Leybold 400035V0011 Digital Controller

 Introduction

Leybold 400035V0011 is a specialized digital drive controller for MAG series magnetic levitation molecular pumps, a spare part for vacuum equipment, responsible for driving and monitoring the operation of turbo molecular pumps.

5 product features:

1. Digital frequency conversion drive, compatible with Leybold magnetic levitation molecular pump, with stable speed control.

2. Real time collection of speed, temperature, and current, with direct output of fault codes for easy troubleshooting of pump body issues.

3. Support the logical linkage of purge and release valves to match the requirements of process gas operating conditions.

4. Equipped with multiple protections against overcurrent, overheating, and rotor stall to prevent damage to the molecular pump rotor.

5. 19 inch half width rack installation, factory standardized wiring interface, easy on-site replacement.

5 product parameters:

1. Single phase AC input 100-240VAC, 50-60Hz.

2. Supports RS232/RS485 communication and can be connected to upper computer or device PLC.

3. Digital IO signal, realizing the interaction of start stop and alarm signals.

4. Rack mounted air-cooled heat dissipation.

5. The working environment temperature is 10-45 ℃.

5 application areas:

1. Leybold MAG series magnetic levitation turbo molecular pump drive matching.

2. Spare parts for vacuum systems in semiconductor etching and coating equipment.

3. Control of high vacuum unit for electron microscopy mass spectrometry analysis instrument.

4. Replacement of vacuum pump control unit for ion beam equipment.

5. Repair and replacement of old controllers for research vacuum chambers.

Overall, Leybold 400035V0011 is a specialized pump drive spare part, with a majority of disassembled parts in the market. It is essential to confirm that it matches the molecular pump model and version before installation.

Product imag
