Nikon 4S013-373-1 Controller Module

Nikon 4S013-373-1 Controller Module

 Introduction

Nikon 4S013-373-1 is a linear motor control board for lithography machines, used for NSR-S204 series machines and often used as a replacement for faulty parts.

5 product features:

1. Linear motor closed-loop drive control, fast motion response, ensuring platform positioning accuracy.

2. Strong and weak electrical wiring isolation, anti machine electromagnetic interference, reducing signal drift and false alarms.

3. Gold plated connectors provide stable contact and are not easily oxidized during long-term operation in dust-free workshops.

4. Onboard over-current and over-voltage protection reduces the risk of damage to other boards due to local faults.

5. Slot direct insertion installation, aligned assembly, no need to modify peripheral circuits for replacement.

5 product parameters:

1. The machine cabinet is powered by DC24V.

2. Adapt to the dedicated bus communication within the lithography machine.

3. Output control linear motor servo circuit.

4. Standard card slot board structure.

5. The working environment temperature is 18-28 ℃, suitable for ultra clean workshops.

5 application areas:

1. Nikon NSR-S204 lithography machine motion platform control.

2. WYL linear motor drive unit for lithography equipment.

3. Spare parts for wafer exposure workstation motion control board.

4. Repair and replacement of faulty Nikon lithography machine boards.

5. Control components for equipment cabinets in semiconductor lithography production lines.

Overall, Nikon 4S013-373-1 belongs to the exclusive board for machines, and there are many disassembled parts in the market. Before being put into production, the version should be checked and the power on test should be completed.

Product imag
