IS200TREAH2A terminal board

IS200TREAH2A terminal board

 Introduction

IS200TREAH2A Terminal Board Product Features

IS200TREAH2A is a special emergency stop safety terminal board for GE gas turbine Mark VIe system, which collects unit protection interlock signals.

1. IS200TREAH2A can be directly replaced with the same model without changing the cabinet wiring

2. Dual channel redundant design, single channel failure does not affect safety protection

3. 24 signal inputs, collecting various contact signals such as overspeed, emergency stop, and trip

4. Fast action response speed, millisecond level output shutdown control signal

5. Plug in high-density terminals, easy wiring, maintenance and disassembly

6. Comes with jumper configuration, can switch signal detection working mode

7. Isolation of strong and weak electrical lines, resistant to electromagnetic interference from power plant frequency converters

8. Coated circuit board, dustproof and moisture-proof, suitable for harsh working conditions

9. Built in static electricity and overvoltage protection, extending the service life of the board

10. Perfectly compatible with the entire IS200 series industrial control system, with strong compatibility

11. Power on automatic channel self-test, quickly locate wire breakage and short circuit faults

12. Each circuit is independently protected to avoid single point failure and false tripping of the entire machine

13. Wide temperature components, stable and continuous operation of high and low temperature control cabinets

14. Board size standard, compatible with rack slots, saving installation space

15. Factory full load aging test, low failure rate during long-term operation

In summary, the IS200TREAH2A terminal board has reliable safety redundancy, easy disassembly, and stable implementation of the entire gas turbine safety interlock signal transmission control.

Product imag
